Boss

Features

  • High Efficiency and energy Saving Design
  • Wide Voltage Range
  • Fitted with Thermal Overload Protector (TOP).
  • High Suction Capacity
  • Superior Mechanical Seal for longer life
  • Anti-friction ball bearings
  • Forged Brass Impeller
  • All Parts Machining Precisly
  • Totally Enclosed Fan Cooled (TEFC) construction resists dust, moisture.
  • CED Coated Pump Parts
  • Batter Insulating Material
  • Easy Maintainable Design
  • Light Weight and Compact Design

Specifications

Suction Lift  Upto 8 meters
Motor Rating  0.09 – 1.50 kW (0.12 – 2.00 HP)
Pipe Size  1/2″ x 1/2″ & 1″ X 1″
Head Range  Up to 60 meters
Discharge Range Up to 4350 LPH
Voltage Range  180 to 250 Volt

MOC

Motor Body Cast iron
Impeller Gun Metal
Suction / Delivery Chamber Cast Iron (CED Coated)
Shaft  SS 410
Mechanical Seal  Ceramic/Carbon/NBR
Cover NDE Cast Iron (CED Coated)

Technical Specifications

Model Name Power (KW) Power (HP) Phase Pipe Sizesuc X Del (Inch) Head Range (MTR) Discharge Range (LPH)
BOSS 12 0.09 0.12 1 1/2″ X 1/2″ 5-20 1000-400
BOSS 50 0.37 0.50 1 1″ X 1″ 5-40 2750-575
BOSS 50X 0.37 0.50 1 1″ X 1″ 5-40 2400-250
BOSS 200 1.50 2.00 1 1″ X 1″ 5-60 4350-900
