Major

Features

  • High Efficiency and energy Saving Design
  • Wide Voltage Range
  • Fitted with Thermal Overload Protector (TOP).
  • High Suction Capacity
  • Superior Mechanical Seal for longer life
  • Anti-friction ball bearings
  • Forged Brass Impeller
  • All Parts Machining Precisly
  • Totally Enclosed Fan Cooled (TEFC) construction resists dust, moisture.
  • CED Coated Pump Parts
  • Batter Insulating Material
  • Easy Maintainable Design
  • Light Weight and Compact Design

Specifications

Suction Lift  Upto 7 meters
Motor Rating  0.37 – 1.10 kW (0.50 – 1.50 HP)
Pipe Size  1″ X 1″”
Head Range  Up to 60 meters
Discharge Range Up to 4400 LPH
Voltage Range  180 to 250 Volt

MOC

Motor Body Aluminium Extruded / Cast iron
Impeller Brass
Suction / Delivery Chamber Aluminium Die Cast / Cast Iron (CED Coated)
Shaft  SS 410
Mechanical Seal  Ceramic/Carbon/NBR
Cover NDE Cast Iron (CED Coated)

Technical Specifications

Model Name Power (KW) Power (HP) Phase Pipe Sizesuc X Del (Inch) Head Range (MTR) Discharge Range (LPH)
MAJOR 0.37 0.50 1 1″ X 1″ 5-35 2400-450
MAJOR 50CI 0.37 0.50 1 1″ X 1″ 5-35 2800-500
MAJOR 100 0.75 1.00 1 1″ X 1″ 5-35 2900-600
MAJOR 100CI 0.75 1.00 1 1″ X 1″ 5-40 3250-500
MAJOR 150 1.10 1.50 1 1″ X 1″ 5-60 4400-1325
