Victor

Features

  • High Efficiency and energy Saving Design
  • Wide Voltage Range
  • Fitted with Thermal Overload Protector (TOP).
  • High Suction Capacity
  • Superior Mechanical Seal for longer life
  • Anti-friction ball bearings
  • Forged Brass Impeller
  • All Parts Machining Precisly
  • Totally Enclosed Fan Cooled (TEFC) construction resists dust, moisture.
  • CED Coated Pump Parts
  • Batter Insulating Material
  • Easy Maintainable Design
  • Light Weight and Compact Design

Specifications

Suction Lift  Upto 8 meters
Motor Rating  0.37 – 1.00 kW (0.50 – 1.00 HP)
Pipe Size  1″ X 1″
Head Range  Up to 35 meters
Discharge Range Up to 4775 LPH
Voltage Range  180 to 250 Volt

MOC

Motor Body Cast iron
Impeller Gun Metal
Casing Cast Iron (CED Coated)
Suction / Delivery Chamber Cast Iron (CED Coated)
Shaft  SS 410
Mechanical Seal  Ceramic/Carbon/NBR
Cover NDE Cast Iron (CED Coated)

Technical Specifications

Model Name Power (KW) Power (HP) Phase Pipe Sizesuc X Del (Inch) Head Range (MTR) Discharge Range (LPH)
VICTOR 50X 0.37 0.50 1 1″ X 1″ 5-25 3100-1110
VICTOR 50 0.37 0.50 1 1″ X 1″ 5-30 3625-750
VICTOR 100 0.75 1.00 1 1″ X 1″ 5-35 4775-1700
